Content reflow fix: CSS inline sizes

Having a smooth page load is part of delivering a good user experience to your audience.

By implementing a content reflow fix on your webpage, you can ensure that users are introduced to your content and brand in the best possible manner.

From a user experience (UX) standpoint, a smooth initial loading experience is vital for engaging new visitors and optimizing for search engines (SEO). It is essential to minimize any potential time wastage for users, and every millisecond counts!

The content reflow issue becomes particularly problematic when following anchor links that should navigate to lower sections of a long page with numerous images. The page position can be so disorienting that users may need to re-navigate or leave altogether.

To help address these issues, I have compiled an article on how to fix content reflow.

What is content reflow?

Content reflow in web development refers to the issue where the dimensions or positions of elements on a webpage change as it is being loaded. This causes the content to reflow or shift on the page and potentially disrupt the user experience.

What is critical inline CSS?

Critical inline CSS is code that helps render the webpage layout as fast as possible before all the assets and content are loaded. The idea is to be able to reduce layout variations when loading the page.

It is called inline because the CSS that first renders the page is included in the initial HTML document received by the browser.

Shortcomings of current solutions

Current solutions for addressing the content reflow issue with images include specifying the width and height attributes in the ‘<img>’ tag or utilizing the CSS aspect ratio boxes fix for responsive images.

The thing is that if you want to display images using art direction, where different aspect ratios are needed for different screen sizes, the existing fixes are not sufficient.

A content reflow fix: CSS inline sizes

CSS inline sizes is a CSS technique used as a content reflow fix for images displayed on your web pages. The page load is smoother because the image sizes are considered part of the critical inline css.

You may use this technique in:

• Static regular images
• Responsive images that fill the container
• Art directed images to display a completely different image per media query rule.
• Images with multiple resolutions, 2x and such
• Any mix of the options above

Code for art directed images

HTML

<figure class="ixi-picture" data-id="img-1">
	<picture class="ixi-picture__picture ixi-picture__placeholder">
		<source media="(min-width: 1025px)" srcset="imgs/1-large-landscape.png, imgs/1-large-landscape@2x.png 2x">
		<source media="(min-width: 700px)" srcset="imgs/1-medium-landscape.png, imgs/1-medium-landscape@2x.png 2x">
		<source media="(max-width: 699px)" srcset="imgs/1-small-square.png, imgs/1-small-square@2x.png 2x">
		<img alt="" class="ixi-picture__img" src="imgs/1-small-square.png">
	</picture>
</figure>

CSS

/* IMG placeholder graphic */

.ixi-picture__placeholder {
   background-color: #ffffd9;
   display: inline-block;
}

/* Media queries for image sizes */

[data-id='img-1'] .ixi-picture__img {
	height: 325px;
	width: 325px
}

@media only screen and (min-width: 700px) {
	[data-id='img-1'] .ixi-picture__img {
		height: 410px;
		width: 600px
	}
}

@media only screen and (min-width: 1025px) {
	[data-id='img-1'] .ixi-picture__img {
		height: 700px;
		width: 1024px
	}
}

Code for responsive images + art directed images

HTML

<figure class="ixi-picture ixi-picture--fluid" data-id="img-8">
	<picture class="ixi-picture__picture ixi-picture__placeholder">
		<source media="(min-width: 1025px)" srcset="imgs/8-large-landscape.png, imgs/8-large-landscape@2x.png 2x">
		<source media="(min-width: 700px)" srcset="imgs/8-medium-landscape.png, imgs/8-medium-landscape@2x.png 2x">
		<source media="(max-width: 699px)" srcset="imgs/8-small-square.png, imgs/8-small-square@2x.png 2x">
		<img alt="" class="ixi-picture__img" src="imgs/8-small-square.png">
	</picture>
</figure>

CSS

/* IMG placeholder graphic */

.ixi-picture__placeholder {
   background-color: #ffffd9;
   display: inline-block;
}

/* Fluid picture */

.ixi-picture--fluid {
	display: flex;
	align-items: stretch;
	justify-content: center;
	flex-direction: column;

}

	.ixi-picture--fluid .ixi-picture__picture {
		align-items: center;
		display: inline-flex;
		margin: 0 !important;
		max-width: 100%;
		max-height: 100%;
		min-width: 100%;
		min-height: 100%;
	}

	.ixi-picture--fluid .ixi-picture__img {
		min-width: 100%;
		min-height: 100%;
	}

/* Media queries for image sizes */

/* Image size is 325x325 */

[data-id='img-2'] .ixi-picture__picture {
	padding-top: calc( (325 / 325) * 100%);
	position: relative;
}

	[data-id='img-2'] .ixi-picture__img {
		width: 325px;
		height: 100%;
		position: absolute;
		top: 0;
		left: 0;
	}

@media only screen and (min-width: 700px) {

	/* Image size is 600x410 */
	[data-id='img-2'] .ixi-picture__picture  {
		padding-top: calc(410 / 600 * 100%);
		width: 600px
	}

}

@media only screen and (min-width: 1025px) {

	/* Image size is 1024x700 */
	[data-id='img-2'] .ixi-picture__picture {
		padding-top: calc(700 / 1024 * 100%);
		width: 1024px
	}

}

CSS inline sizes demo

There are two demo pages available for you to check out. One is a regular page load where all images are included as part of the initial load. The other one uses Lazysizes to lazyload the images. That means that the images are loaded only when needed, after the initial page load has occurred.

Demo video

Links

Regular image load

Demo with regular page load Demo with Lazyload

The demo file are in Github as well:
https://github.com/alberto-torres/css-inline-sizes/

How to use

To test the loading sequence do the following:

• Load the demo in your web browser
• Lower your bandwidth using the inspector tool on your browser and reload the page.
• Use the responsive design mode to resize the screen as the page loads.

Media queries

As you play around with the demo, you’ll see that the correct layout will display even if the screen size is changing as the page loads. The demo uses 4 different media queries for different screen widths. These are:

/* Small size */
/* (max-width: 699px) - used in <source> to enforce media query */

/* Medium size */
@media only screen and (min-width: 700px) {}

/* Large size */
@media only screen and (min-width: 1025px) {}

/* Extra large size */
@media only screen and (min-width: 1200px) {}

Demo layout CSS

The demo includes CSS code for the different layouts shown. These are:

• Large image, hero style
• Flexbox layout for different image sizes
• A fluid container with a responsive/art-directed image
• A floated image as part of a paragraph text

This code is just for demo purposes and it is not required for the CSS inline sizes fix.

Placeholder graphic

A simple placeholder graphic to let the user know that an image will eventually load in there. Please feel free to modify it and make it fit your visual identity.

This is being referenced via the ixn-picture__placeholder class in the <picture> tag. Below is the CSS:

/* Placeholder graphic */

.ixi-picture__placeholder {
	background-size: 100% 100%;
	display: inline-block;
}

Images need a reference

To be able to provide custom sizes for each image you need a way to reference them by a unique identifier. In the demo, we use the data attribute in the outer tag. I believe this is the most unobtrusive way.

HTML

<figure class="ixi-picture" data-id="img-1">

CSS

[data-id='img-1'] .ixi-picture__img {}

Lazyload

Most modern websites will use a lazyload technique. The demo uses Lazysizes to support art direction. To use lazysizes add the following code to your critical inline css:

/* Lazyload */
.lazyload, .lazyloading {
	opacity: 0;
}

Also, update your HTML according to your lazyload implementation. For this case:

• Change the attributes src and srcset to data-src and data-srcset.
• Add the lazyload class to all <img> tags

You also need to include the CSS and JS files required. You may get them from the Github repo.

<link rel="stylesheet" href="lazyload.css">

<script src="lazyload.js"></script>

Image specifications

Below is a table with all the different images used in the demo. For example, the image with the ID 1 is served in 3 different screen sizes, have different aspect ratios and support 1x and 2x resolutions.

Expanding the use of CSS inline sizes

I have implemented this technique in various advanced elements such as image galleries, image sliders, modal boxes, and even combined it with JavaScript. To see an example, check out this page, and this whole website should be loading smoothly.

Browser support

The technique is pretty basic and should be supported widely. If you are using the CSS aspect ratio fix you’ll need support for the calc() CSS property.

Conclusion

With CSS inline sizes you may fix the content reflow issue for advanced images. This improves the user experience and search engine optimization by offering a smooth first load.

CSS inline sizes involve the use of HTML and inline CSS to assign specific width and height values to different image sizes. This approach supports art direction, responsive images, and accommodates various screen resolutions such as 2x, 3x, and beyond.
